Replacing the turn signal light in the side mirror
How to disassemble a mirror on a Skoda Octavia A7
dismantling the Skoda Octavia A5 mirror
Replacing the landing zone lighting lamps in the mirrors of a Skoda Octavia A7
REPLACEMENT OF TURN SIGNAL FOR PASSAT B6 1K0949101 1K0949102 without service station
Installation and removal of the rear view mirror for Skoda A5 FL
Replacing the turn signal in the mirror on Passat B6
Replacing mirror repeater for Octavia A5
HOW TO CORRECTLY CHANGE THE MIRROR ON A SKODA
The mirror on the Skoda Octavia A5 has gone crazy
Hidden features of the Skoda key fob
- How to reset an error when replacing a light bulb on a Skoda Octavia FL – 1 answer
Described in detail, with a bunch of photographs, see here Skoda Octavia A5 Replacing the left repeater (in the mirror).
For the second option, see the link here.
You can also watch a couple of videos
Subscribe
to our channel in
Index.Zen
Even more useful tips in a convenient format
Due to numerous requests from site readers, I am posting information on repeaters in the mirrors on our Octavias.
Sometimes the diodes that are in the turn signal repeaters fail. The LED just doesn't change separately. The repeater assembly can be replaced. Moreover, this greatly simplifies replacement; you don’t have to solder anything or anything.
By the way, when the diode stops working, by connecting a VCDS diagnostic scanner you can find this error.
In ETKA which can be customized to your VIN - this part is called a turn signal light for exterior mirrors .
3T0 949 101 – left.
3T0 949 102 – right.
But we are not in a hurry to buy the original; as always, its price is not the cheapest. Almost the same part can be found on Ali https://ali.pub/25zizp for almost three times cheaper.
The part has been tested and is of fairly high quality, so it makes sense to buy. You can also buy LEDs for our car on Ali.
Article rating:
Payment via PayPal
After selecting payment via PayPal, the PayPal payment system will launch, where you need to select the payment method: bank card or PayPal account.
If you already have a PayPal account, then you need to log into it and make a payment.
If you do not have a PayPal account and you want to pay using a bank card via PayPal, you need to click on the “Create an Account” button - shown with an arrow in the picture.
PayPal will then prompt you to select your country and provide your credit card information.
After specifying the information required to make the payment, you must click on the “Pay Now” button.
Official website of the PayPal payment system https://www.paypal.com
Solutions to issues with repeaters and how to change the side indicator
What's in the article:
- how to disassemble the repeater in the rear view mirror on a Skoda, - the article number of the right and left repeaters in the mirrors, - if the repeaters do not work, what to check, - the turn signal switch is faulty, - when the ignition is turned off, the right turn signal is on, - the right front turn signal is constantly on - possible solutions - when the ignition is turned off, the right direction indicator lights up.
Catalog numbers - mirror turn signals for Octavia A5
Articles for replacing repeaters in mirrors.
VAG 3T0 949 101 – left VAG 3T0 949 102 – right
Repeat on Aliexpress and much cheaper >>
If the diodes in the repeater do not light up, first check the contacts. If everything is fine with them, then the entire LED block is replaced.
If the repeaters in the mirrors do not work, there is no power and at the same time all the other door electrics are working properly - we check the previous ones. Also, look at Vasya, maybe you have it disabled by a cord.
The turn signal switch on SKODA is buggy
How the problem manifests itself: You turn it on so that the right one blinks, the left one blinks periodically. You have to support it with your finger for the right one to work.
Solution: Clean the switch. Disassemble and look at the contacts - most likely, something has shorted or bent. It happens that the problem goes away on its own after a week of normal travel.
For those who don’t know how to remove the module block that is under the steering wheel.
We remove the bottom cover, it is fastened with latches, pull out the board and then remove the top cover, which is also fastened with two latches. And pull out the turn signal switch. We remove the steering wheel. If this does not help, you will have to change the steering column switch unit. Expensive pleasure.
When the ignition is turned off, the right turn signal lights up
Another problem: The right turn signal on the Skoda freezes. After turning off the ignition it lights up. Removing the terminal from the battery. Does not help. What could it be and how to treat it?
Most likely the microcircuit in the brain has burned out.
The right or left front turn signal is constantly on - possible solutions
It happens that the right front turn signal is constantly on! It goes out when you remove the terminal, but it stays on all the time. When you turn on the hazard lights, it still lights up, and when you turn on the turn signal, it still lights up.
What to do: disassemble the steering column, clean the contacts on the turn signal lever and replace the fuse. The key on the comfort unit may have been knocked out. It can be treated by repairing the block or replacing it. This happens when non-standard xenon or diodes are installed in the turn signals.
How to understand what knocked out the key?
The key is one of the exit channels from the bookmaker or brains. The board burns out, or rather a specific channel that is responsible for cold or hot polling of car lamps. The survey is a test of the functionality of those same lamps. BC checks that all lamps are working properly and are in place based on their resistance. By installing diodes or collective farm xenon without turning off the lamp polling programmatically, the BK fails because the resistance is completely different. Some masters rewrite the BC settings to another output, the “pin” or “key” bypasses the one that burned out. Not everyone can do the bypass. Selected masters are taken. To do this, you need a VAS-PC with a branded disc version no higher than 19.47. You need to reassign the output channel to the turn signal. And accordingly, rearrange the wire in the chip, where you will reassign the channel.
This topic is asked in my PM. And since it’s sometimes difficult to quickly find the photo report you need on the Internet, I’ll allow myself to post an excellent photo report from the drive from Yuriuzzz.
The side turn signal is integrated into the rear view mirror housing. The replacement of the left side turn signal is shown; the right side turn signal is replaced in the same way.
1. Press your finger on the bottom of the reflective element, tilting the reflective element.
2. Pry up the reflective element with a flat wooden lever, placing a piece of cloth under it...
3. ...and remove it from the mounting of the electric drive mechanism.
4. Disconnect the two lugs of the electric heating wires from the reflective element.
This is how it is shown in the picture.
5. Place the mirror housing in service mode by turning it clockwise until it stops.
6. Using a screwdriver, press out the upper...
7. ...and side housing clamps.
8. Remove the upper part of the mirror housing.
9. Remove the spacer.
10. Remove the three screws securing the bottom cover.
11. Remove the lower mirror cover along with the turn signal.
12. Squeeze the latch and disconnect the wiring harness block from the turn signal.
13. Press the latch...
14. and remove the side turn signal.
15. Install the side turn signal and rear view mirror parts in the reverse order of removal.
Material taken from the book “Step-by-step repair of the Skoda Octavia A5 in photographs”
Collections on the topic:
How to change the turn signal bulb in the side rear view mirror
The heated mirror does not work, mirror part number, how to remove the mirror element
Tell me what kind of glue to use to glue the rear view mirror to the windshield - Skoda A5
Payment via WebMoney
After selecting payment via WebMoney, the payment system will launch, where you need to select the payment method: bank card or WebMoney wallet.
If you already have a WebMoney wallet, then you need to log into it and make a payment.
If you do not have a WebMoney wallet and you want to pay in another way, you need to select any of the methods that WebMoney offers and make the payment
After specifying payment details and confirming payment, payment for the goods will occur.
Official website of the WebMoney payment system https://www.webmoney.ru/
Downloading a book
After successfully completing the payment (by any method) and returning to the KrutilVertel store from the payment system website, you will be taken to the successful payment page:
On this page you need to indicate your e-mail, where access to download the book will be sent.
If you are already registered on our website, then simply follow the link to your personal account.
The book you purchased will be in your personal account, from where you can always download it.
Please note that after making the payment, you need to return back from the payment system website to the KrutilVertel website.
If for some reason you did not return back to the site and closed the payment system tab with a message about the successful completion of the payment, please let us know - we will send you a letter indicating access to download the book.
VESKO-TRANS.RU
AutoNews / Reviews / Tests
Replacing the Turn Signal in the Mirror of Skoda Octavia A5
Skoda Octavia A5 FL 1.8 tsi ›Logbook› Changed the left repeater (in the mirror)
This topic was brought up because of a problem. An error has occurred in the light bulb. And I actually turned everything on and went to inspect the car. I was walking. Everything lights up twice. Mom, this is junk. Knowing that there are diodes in the mirrors, I thought about them at the end of the process! Unfortunately, no, they did not work on purpose.
3 diodes closer to the outer edge of the LEFT mirror began to work through the same thing. So they blink, no. Only 1 with the edge at the door worked clearly. I went to refuse the guarantee and refused. The master said. THERE IS ONE CHARACTERISTIC, IF STONE AND CRACK ARE AVAILABLE, THEN LET'S EVALUATE AGAIN.
So I found, in particular, a small crack of 0.4 mm.
They offered to change them, but the frog strangled me by paying 1200 for the repeater, although with a reduced cost of 800 works, 1000 changes.
I ordered this VAG light 3T0949101 for (left turn mirror). 600 rub.
In the unique annotation that hangs on the Internet, everything is as simple as it is in reality. Someone wrote that it took 20-30 minutes to delete the work.
After carefully studying all kinds of reports and annotations, I collected everything in my head and went swimming, the result took about 15 minutes (disassemble-install-collect)
The photos for our client are still signed and it is better to study the assembly annotation, then it is easier to understand how to remove everything!
REMOVING AN ELEMENT Mirror
:
Disassembling the Skoda Octavia A5 mirror
dismantling the door trim of Skoda A5
.
Rear view mirror arrangement and removal of Skoda A5 FL
Replacing the turn signal
in
Driver's
mirror The procedure is not complicated, as you can see in the video on the left. 1. Place the mirror in the working position (lean back all the way) 2. Lower mirror element
in the lower position all the way.
(I did this with my hands carefully because it does not hit the maximum bottom from the electronic control). The top shows the fastening of the glass element at the top 2 and bottom. 3. Using a flat head screwdriver, he leaned back slightly, first with his left ear and then with his right. 4. Hands, carefully grasping the mirror element, began to bend down with a slight effort and move towards themselves to remove the lower fastenings. they come off and yay, the mirror element
is in your hand! 5. DON'T FORGET TO GIVE THE CLOCK WITH THE MIRROR! BUT VERY careful because he keeps everything on his nose! I pressed the contact with my hand and shook the chip, first one, and then the second, removing them. (Terrible for the heating).
Removing the mirror cover
: 6. Unscrew the 2 screws 7. Remove the 4 plastic fasteners from the latches.
8. Carefully slight force
. another YAAAAAA.
DISABLED DEVELOPMENT OF PLASTIC LOWER AND REPATER
: 9. Remove 2 screws 10. Disconnect 3 fasteners.
2 from the mirror element (where the screws are) and 1 behind the mirror.
You need to start with what is 1 distance behind the mirror on the outside. 11. Pull down and away. URAAAAAA! the last step is to replace the band repeater itself
:
12. Remove 2 more screws from the black bottom plate. 13. Disconnect the chip from the repeater.
Reassembly is reversed, and NOTA
on
Screws
!
They are different
!
If anyone has questions, ask, if not everyone understands and needs more detailed information, I’ll tell you)) I tried not to miss anything from this disassembly/assembly. I hope someone will help my instructions with some minor nuances))))
Problems when paying with bank cards
Sometimes difficulties may arise when paying with Visa/MasterCard bank cards. The most common of them:
- There is a restriction on the card for paying for online purchases
- A plastic card is not intended for making payments online.
- The plastic card is not activated for making payments online.
- There are not enough funds on the plastic card.
In order to solve these problems, you need to call or write to the technical support of the bank where you are served. Bank specialists will help you resolve them and make payments.
That's basically it. The entire process of paying for a book in PDF format on car repair on our website takes 1-2 minutes.
If you still have any questions, you can ask them using the feedback form, or write us an email at [email protected]
Replacing the turn signal in the mirror of a Skoda Octavia A5
Good day to all!
As I already promised, I’m posting a detailed entry about replacing the right turn signal repeater in the rear view mirror. (Everything is the same for the left one)
I already said earlier that at first one LED section failed, and literally the other day all the sections completely failed ((
Ordered to live long, as they say
